MYIR MYD-J1028X Development Board
MYIR MYD-J1028X Development Board has a high-performance MYC-J1028X CPU Module and a baseboard for a complete evaluation. It is used to evaluate the NXP LS1028A Processor which features dual Arm® Cortex-A72 cores, with integrated 3D GPU for HMI. It also has time-sensitive networking (TSN) -enabled Ethernet switch and Ethernet controllers to support converged IT and OT networks.
Features
- MYC-J1028X CPU Module as Controller Board
- 1. GHz NXP Layerscape LS1028A Application Processor based on Dual Arm® Cortex-A72 Cores
- 2GB DDR4, 8GB eMMC Flash, 32Kbit EEPROM
- 1 x USB3.0 Host, 5 x Gigabit TSN Ethernet, 1 x WIFI Module interface, 1 x 5G Module interface
- 1 x SSD Module Interface, 1 x Micro SD Card Slot
- 1 x DP Display Interface, 1 x Audio out
- Supports Ubuntu and Real-time Edge Images based on Linux Kernel
- Optional USB Camera Module and RPI Module
Overview
Publicado: 2022-06-27
| Actualizado: 2025-02-20
