GE Energy/Lineage Power 12V Mega TLynx™ DC-DC Power Module is a non-isolated DC-DC converter that can deliver up to 30A of output current. Operating over a wide range of input voltage (Vin=6VDC-14VDC), the 12V Mega TLynx provides a precisely regulated output voltage from 0.8VDC to 3.63VDC, programmable via an external resistor. Features include remote On/Off, adjustable output voltage, over current and over temperature protection, output voltage sequencing and paralleling with active current sharing. GE Energy's Tunable Loop™ allows the user to optimize the dynamic response of the converter to match the load with reduced amount of output capacitance leading to savings on cost and PWB area.
Delivers up to 30A output current
Start-Up into a pre-biased output
Overcurrent and Over Temperature Protection
Input Voltage Range: 6VDC to 14VDC
Programmable Output Voltage: 0.8VDC to 3.63VDC
High Efficiency: 92.9% at 3.3V full load (VIN=12VDC)
Small Size/Low Profile: 33mm x 13.46mm x 10mm (1.3 in. x 0.53 in. x 0.39 in.)
